| Parameter | Value |
|---|---|
| External dimensions (L × W × H) | 500 × 240 × 265 cm |
| Sauna cabin (internal) | 240 × 220 cm |
| Vestibule (internal) | 200 × 220 cm |
| Structure | C24 (EN 338) |
| Facade | Thermory® 26 × 140 mm |
| Wall and roof insulation | 100 mm / U = 0,35 W/m²K |
| Glazing | ESG 8 mm |
| Heater (standard) | HUUM DROP – 9 kW, 400 V |
| Capacity (persons) | 6–8 |
| Total weight | ~2400 kg |
| Roof covering | EPDM 1,2 mm |
- HUUM DROP 9 kW heater with UKU Wi-Fi control
- HUUM stones (55 kg, rounded pebbles)
- Two-level benches in knot-free aspen
- Vestibule with bench and thermowood coat rack
- Full-glass ESG 8 mm door to the cabin
- LED lighting in the cabin and vestibule
- Adjustable supply and extract ventilation
The plan includes foundation dimensions, connection points and the crane working zone.
Selected installations of this model for customers across Europe.
Customer reviews
„Seven weeks from order to installation, exactly as promised. The vestibule was the best decision – we use the sauna all year round.”
Questions about this model
What can the HUUM UKU Wi-Fi control do?
You start the sauna from a smartphone app – set the temperature and start time, and the system notifies you when the cabin is ready. A child lock and door sensor are built in.
Is the vestibule heated?
The vestibule benefits from the cabin's heat and the fully insulated walls, staying comfortable even in winter. Optionally, we install a 230 V electric heater with a thermostat.
What power supply does the Vetta need?
The standard HUUM DROP 9 kW requires 400 V (3×16 A). Lighting and sockets in the vestibule run on a separate 230 V circuit.
Will the roof carry mountain snow loads?
The C24 rafter roof carries snow load zone III (up to 1.2 kN/m²). For mountain locations we reinforce the structure to zone IV as part of a custom design.
